Hoshizaki KM-61BAH, Ice Maker, Air-cooled, Self Contained, Built in Storage Bin

KM61BAH, Ice Maker, Air-cooled, Crescent style ice, Up to 71 lbs of ice produced per 24 hours, Up to 38 lbs of built-in storage capacity, Slide in door with durable stainless steel exterior

Compare
SKU: KM-61BAH Categories: , ,

Description

The KM-61BAH is capable of producing approximately 71 lbs of crescent cubed ice. This Undercounter Air-cooled, Self Contained, Built in Storage Bin ice maker stores up to 38 lbs of ice, which makes it ideal for small bars, hotel lobbies, and office break rooms. It features the CycleSaver? design and includes the EverCheck? alert system making the unit simple to maintain. The KM-61BAH requires a Single phase, 115v/60/1 electrical connection. ENERGY STAR qualified. Please consult the Specification Sheet for additional details.

  • Dimensions: 17-3/4″ W x 24-1/4″ D x 39″ H
  • Up to 71 lbs of ice produced per 24 hours
  • Up to 38 lbs of built-in storage capacity
  • Produces crescent ice
  • Slide in door with durable stainless steel exterior
  • Ice maker with built in storage
  • EverCheck? alert system
  • CycleSaver? design
  • R-134a refrigerant
  • HS-5061 drain pump assembly, sold separately
  • Ambient temperature range: 45 – 100?F
  • Water temperature range: 45 – 90?F
  • Water pressure: 10 – 113psig
  • Voltage range: 104 – 127V
  • 3.4 amps (15 Amp Max fuse)
  • 10.6 kwh/100 lbs.@ 90/70
  • Single phase, 115v/60/1
  • ENERGY STAR Qualified
  • Three Years: Parts & Labor warranty on entire machine.
  • Five Years: Parts & Labor warranty on evaporator.

Certifications: NSF, ISO 9001:14001, ETL Sanitation Listed, ENERGY STAR Qualified

ENERGY STAR? Qualified: Yes

Plumbing Specs: 1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent

Utility Consumption: 10.6 kWh per 100 lbs @ 90/70, 20.6 gal of Potable Water per 100 lbs @ 90/70

Operating Limits: Ambient Temp Range: 45 – 100?F, Water Temp Range: 45 – 90?F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V

Spec Sheet:?
Instruction Manual:?
Parts Manual:?
Service Manual:?
CAD/Revit Files:?
Warranty Statement:?
Technical manual:?

Additional information

Weight117 lbs
Dimensions21 × 27 × 39.5 in
